PLEASE ASK FOR INFO about restoration done and some more job to do- actually in running shape – last sea trial July 2019
BUILDER: W. De Vries Lentsch – Amsterdam
YEAR: 1938 and totally restored in 1994 and 2011
DESIGNER: W. De Vries Lentsch
INTERIOR DESIGNER:
L.O.A: 72 ft
BEAM: 15 ft
DISPLACEMENT: 55.880 kg
Capacities
FUEL CAPACITY: 3800 lt
WATER CAPACITY: 2000 lt
RANGE:
SPEED: 10 knots at 1000 RPM
3. MACHINERY
ENGINES: 2 x 120 HP – 8 cylinders – Dutch Gardner
ENGINE HOURS:
GEARSBOXES:
PROPULSION:
Generators & Electricity
GENERATORS:
GENERATOR HOURS:
ELECTRICITY:
SHORE POWER:
BATTERIES: 4 for engines 2 for services 1 for generator all indipendent but with possibilities to change from 12 to 24 volts
AIR CONDITIONING: Cool and Warm
Other machinery
Water maker
Water Boiler
Bilge pumps and Sanguineti WC
Accomodation
• 3 DOUBLE LARGE CABINS WITH TWO TOILETTES WITH SHOWER
• CREW CABIN WITH TOILETTE AND SHOWER
Hull material steel
Hull colour white
Hull shape S-bilged
Keel type box keel
Superstructure material wood
Deck finish teak
Superstructure deck finish paint
Cockpit deck finish teak
Dorades yes
Window frame stainless steel
Window material glass
Deckhatch yes
Portholes yes
Mast can be lowered yes
Steadying sail with mast yes
Inside helm position yes
Engine cooling system freshwater heat exchanger
Drive shaft
Shaft seal yes
Engine controls mechanical
Gearbox hydraulic
Bowthruster electric
Propeller type fixed
Propeller blades 4
Propeller shaft material steel
Shaft lubrication grease
Manual bilge pump yes
Electric bilge pump yes
Bilge alarm yes
Electrical installation 12 & 24 V DC & 230 V AC
Generator Kohler wet exhaust
Batteries yes
Start battery 4 x 135 AH 12 V for 2 x 24 V 135 Ah
Service battery 2 x 135 AH 12 V for 12 V 270 AH
Generator battery 1 x 88 AH 12 V
Battery monitor yes
Battery charger yes
Shorepower with cable
Watermaker yes
Trimtabs fixed
Compass yes
Electric compass Robertson dataline
Depth sounder/log Robertson Dataline
VHF Sailer RT 2046
Autopilot Robertson Dataline
Rudder angle indicator yes
Radar Raytheon R10X
Plotter Raytheon Raychart 600
Transmitter Furuno Tranceiver FS1500T
Navigation lights yes
Searchlight yes
NEW PICS 2019
NEW
pictures -sea-trial
An example of what happend to another yacht in Dunkirk
